LABELTUBE-60 Automatic Empty Tube Sticker Labelling Machine
PRODUCT OVERVIEW
The Automatic Empty Tube Sticker Labelling Machine Model LABELTUBE-60, Capping and Sticker Labeling Machine, Plugging, Capping and Sticker Labeling Machine is one of the most user friendly Sticker Label applicator on Empty Tube. The Machine incorporates latest sophisticated Micro Processor Control Label Dispensing system with user friendly Sensing system for Label and Product. The Machine is suitable for applying Wrap Round Label on Empty Plastic or Aluminium Tubes of Round Shape. Machine can be customised to meet individual customers requirement having different sizes of Tubes. Machine with automatic Tube Feeding system and similarly pneumatically operated Tube ejection System after Label Application. Machine designed for easy and quick change over from one size to another size of tube with the help of required change parts. Special features of applying Twin Label on products from Single Label Roll or application of Label on product at regular intervals is also available on this machine.
PRODUCT OVERVIEW
TECHNICAL SPECIFICATIONS
| Label Height | 8 mm to 70 mm Standard* |
| Label Length | 12 mm Minimum |
| Label Roll Dia. | 300 to 400 mm depending on label height |
| Core Dia. | 75/76 mm |
| Gap Between two Labels | appx. 3 mm |
| Tube Diameter and Height | Actual Product Samples required |
| Electrical | 220 VAC Single Phase Power Supply (50/60 Hz) |
| Power | 1.5 Amp. , 0.75 Kw |
| Filtered Compressed Air | 4 to 5 Bar Air Pressure required |
| Speed | Up to 50 Labels per minute depending on Product and Label Size |
| Overall dimension | 1750 mm(L) X 900 mm(W) X 1800 mm (H) |
| * Specification can be changed as per customers requirements | |
